89mm T51 Ballistic Button Bit

Good quality Tapered Rod for sales
Prodrill Products are suitable for us, we do almost 10 years business. You can test the products

—— Mr Moises

I'm Online Chat Now

89mm T51 Ballistic Button Bit

China 89mm T51 Ballistic Button Bit supplier

Large Image :  89mm T51 Ballistic Button Bit

Product Details:

Place of Origin: China
Brand Name: PRODRILL
Certification: ISO:9001, CE
Model Number: 89mm T51

Payment & Shipping Terms:

Minimum Order Quantity: 5 Pcs
Price: $1~$300/pcs
Packaging Details: Wooden box
Delivery Time: 3 to 15 days
Payment Terms: T/T, L/C, Western Union etc.
Supply Ability: 10000Pcs/Month
Contact Now
Detailed Product Description
Type: Drill Bit Machine Type: Drilling Tool
Material: Carbide Processing Type: Forging
Use: Ore Mining


Thread Button Bits: High quality and several thread with various carbide tips like YK05 are available. All products can be developed upon customers' request.
Prodrill supply all kind of button bits with Rope thread R22, R25, R28, R32, R35, R38 and T thread, T38, T45, T51, ST58, ST68, T60 etc. for world famous brand drill rig.

Main button bits is:
R32-43MM, R32-45MM, R32-51, R32-64, R32-76;
T38-64, T38-76MM, T38-89, T38-102MM;
T45-76MM, T45-89MM, T45-102MM;
T51-89MM, T51-102MM, T51-127MM etc.
all face design, flat face, drop-center face, normal body and retrac body.

Product features

Premium designs and steel and premium tungsten carbide insert grade T6 supplied by Boart Long year, Offers industry-leading strength and penetration rates for more productivity,Excellent straightness and hole clean quality, Get max.drilling performance for rock drill with long life .



  Top hammer bits with T51 thread
Part number Diameter  Buttons  Buttons  Flushing gauge Flushing  front Body Front
gauge  front
89ND 89mm 8x12mm 6x11mm 1 4 Normal Dropcenter
89RD  89mm   6x11mm 1  4 Retrack Dropcenter
 Top hammer bits with T45 thread
Part number Diameter  Buttons  Buttons  Flushing gauge Flushing  front Body Front
gauge  front
66RD  66mm   4x10mm 1 x 8mm  0 4 Retrack Dropcenter
70RD  70mm  8x10mm  5x10mm 0 4 Retrack Dropcenter
76ND 76mm 8x12mm 5x11mm 0 4 Normal Dropcenter
76RD  76mm  8x12mm  5x11mm 0 4 Retrack Dropcenter
76RD L  76mm  8x12mm  5x11mm 0 4 Guidebit  Dropcenter
89ND 89mm 8x12mm 6x11mm 1 4 Normal Dropcenter
89RD  89mm 8x12mm 6x11mm 1 4 Retrack Dropcenter
Top hammer bits with T38 / R38 thread
Part number Diameter Buttons Buttons Flushing  gauge Flushing   ront Body Front
gauge front
64RD 64mm 8x10mm  4x10mm 1x8mm  0 4 Retrack Dropcenter
76ND 76mm 8x12mm 5x11mm 0 4 Normal Dropcenter
76RD 76mm 8x12mm  5x11mm 0 4 Retrack  Dropcenter
64RD 64mm 8x10mm  4x10mm 0 Retrack Dropcenter
76ND  76mm 8x12mm 5x11mm 0 4 Normal Dropcenter
76RD 76mm 8x12mm 5x11mm 0 4 Retrack Dropcenter
 Top hammer bits with R32 Thread
Part number Diameter  Buttons  Buttons front Flushing Flushing  front Body Front
gauge  gauge
41NF 41mm 6x8mm  2x 8mm 1 2 Normal   Flat
43NF 43mm 6x9mm  2x8mm 1 2  Normal  Flat
45NF  45mm  5x10mm  2x9mm 2 1 Normal Flat
  48ND  48mm   6x10mm   3x9mm  2 3 Normal Dropcenter
48RD 48mm  6x10mm  3x9mm  2 3 Retrack Dropcenter
51ND  51mm   6x10mm  3x9mm 0 3 Normal Dropcenter
51RD 51mm  6x10mm  3x9mm 0 3 Retrack Dropcenter


Our main products are as below:

Construction & Mining & Rock Drill Tools:

A. DTH Hammer and Bit (2''-24''), Overburden Drilling System; RC System.

B. Top Hammer (drill hole dia.: 33 ~ 152mm).

1) Thread Tools (Button Bits, Rod, Coupling, Shank Adaptor): (R25/28/32/38, T38/45/51, ST58,GT60).

2) High Rang Soundless Cracking Agent (dia. 40 ~ 50mm).


Quarrying Drill Tools (drill hole dia.: 17 ~ 45mm).

1) Taper Drill Tools (Bit: button/chisel; Rod: Tapered/Integral), Carbide Tips, Segment, Grinding Wheel, Grinder.

3) Pneumatic Rock Drill: Hand-held (Y24, TY24C), Air leg (YT28) and Gasoline (YN27J).

4) Expansive Mortar (dia. 30 ~ 35mm); Hydraulic Rock Splitter PD40-250, Aluminum Cylinder.

5) Air Pushing Bag, Water Bag; Pneumatica Splitter G10, Hand Splitter, etc.

6) Hydraulic Breaker hammer, Paving breaker TPB40, 60, 90 for rock or concrete demolition.

7) PD28, PD45, PD90, PD115/HC20 Excavator mounted rock drilling.
