PD1200 Cluster Hammer DTH Hammer for rotary drill rigs

China PD1200 Cluster Hammer DTH Hammer for rotary drill rigs supplier

Large Image :  PD1200 Cluster Hammer DTH Hammer for rotary drill rigs

Product Details:

Place of Origin: China
Brand Name: PRODRILL
Certification: ISO:9001
Model Number: Cluster DTH Hammer PD1200

Payment & Shipping Terms:

Minimum Order Quantity: 1 SETS
Price: $25000
Packaging Details: WOODEN BOX
Delivery Time: 10-15 DAYS
Payment Terms: T/T, L/C,western union etc.
Supply Ability: 1000 set/month
Contact Now
Detailed Product Description

PD1000  Cluster Hammer





P/N

PD1200

Diameter (mm)

1200

Height (mm)

1400(without pilot bit)

Total height(mm)

2600

Weight (Kg)

2450

Total weight (Kg)

3500

No. of Sub-hammers

8



Technical Data

Air pressure

1.0Mpa

1.8Mpa

2.4Mpa

Air consumption

72 m³/min

144 m³/min

208 m³/min

Remark: Above data for reference only, for more specific information, please contact with our market manager.

A brief introduction to PD series Super Jumbo Cluster Hammer



Pro Drill series Super Jumbo Cluster Hammer Drill, is designed to fulfill piling purpose on rotary drill rigs, especially under hard rock condition. We are the firstly and only one factory to produce this new products, This Jumbo Cluster Hammer adopts the typical Bauer square drive, which can match with most of the rotary drilling rig prevailing on the market.

To overcome the short of traditional rotary drill rig - low drilling efficiency in hard rock formation, the PD Cluster Hammer Drill adopts cluster method to let several DTH hammers work together, which makes it possible to use small size DTH hammers drilling big size holes. And in this way, the work efficiency is greatly improved by dozens of times, compared to traditional rotary drill.

According to the demand current market, we now launch 660mm, 800, 1000mm, 1200mm, 1300mm, and 1500mm diameter cluster hammer drill, and also we can customize specific sizes, according to particular demand of customers.





◆ PD series Jumbo Cluster Hammer features

1. PD series cluster hammer adopts the typical Bauer square drive, can match with most of the rotary drilling rig prevailing on the market;

2. PD series cluster hammer use specially designed air intake, transmit air through a swivel, thus make the pipeline always rotates under a sealed environment.

3. The pipeline takes strict standard high air pressure hose, and lower cost by selecting most suitable model according to different air consumption.

4. High pressure joints are applied between pipelines, together with anti-trip hinge, which is easy to dissemble and safe to use.

5. PD series cluster hammer has the advantage of reasonable structure, simply while reliable, easy to maintenance, convenient to use on rotary drill rig, and low cost.

6. PD series cluster hammer can be customized according to specific requirements.
