Product Details:
Payment & Shipping Terms:
|
| Type: | Drill Bit | Machine Type: | Drilling Tool |
|---|---|---|---|
| Material: | Carbide | Processing Type: | Forging |
| Use: | Pneumatic Grinding |
Grinder PD 200
Description: PD200 Air grinder sed with small rock drill on non-power source scene and working site, solving the drill's tool sharpening problem.It is a ideal supporting tools for air rock drill and diesel engine.It brings
more convenience, and it will improve the rock drilling work efficiency and bring the considerable economic efficiency.
Product features:
PD200 Air grinder sed with small rock drill on non-power source scene and working site, solving the drill's tool sharpening problem.It is a ideal supporting tools for air rock drill and diesel engine.It brings more convenience, and it will improve the rock drilling work
| Model | PD125 | PD200 |
| Rotation speed | 3500 RPM max | 3500 RPM max |
| Motor power | HP2 | HP2 |
| Sharpening angle | 110 degree | 110 degree |
| Sharpening radius | 125mm | 125mm |
| Operating pressure insufficient | 6.0bar | 6.0bar |
| Air consumption at 6 bar | 1.5mc/min | 1.5mc/min |
| Abrasive grinder diameter | 152mm | 152mm |
| Grinder height | 70mm | 70mm |
| Grinder thickness | 22mm | 22mm |
| Grinder hole(diameter) | 32mm | 32mm |
| Bench version weight | 36kg | 36kg |
| Portable version weight | 37kg | 37kg |
Our main products are as below:
Construction & Mining & Rock Drill Tools:
A. DTH Hammer and Bit (2''-24''), Overburden Drilling System; RC System.
B. Top Hammer (drill hole dia.: 33 ~ 152mm).
1) Thread Tools (Button Bits, Rod, Coupling, Shank Adaptor): (R25/28/32/38, T38/45/51, ST58,GT60).
2) High Rang Soundless Cracking Agent (dia. 40 ~ 50mm).
Quarrying Drill Tools (drill hole dia.: 17 ~ 45mm).
1) Taper Drill Tools (Bit: button/chisel; Rod: Tapered/Integral), Carbide Tips, Segment, Grinding Wheel, Grinder.
3) Pneumatic Rock Drill: Hand-held (Y24, TY24C), Air leg (YT28) and Gasoline (YN27J).
4) Expansive Mortar (dia. 30 ~ 35mm); Hydraulic Rock Splitter PD40-250, Aluminum Cylinder.
5) Air Pushing Bag, Water Bag; Pneumatica Splitter G10, Hand Splitter, etc.
6) Hydraulic Breaker hammer, Paving breaker TPB40, 60, 90 for rock or concrete demolition.
7) PD28, PD45, PD90, PD115/HC20 Excavator mounted rock drilling.
