T51 Carburized Extension Rod for Bench Drilling

China T51 Carburized Extension Rod for Bench Drilling supplier
T51 Carburized Extension Rod for Bench Drilling supplier T51 Carburized Extension Rod for Bench Drilling supplier

Large Image :  T51 Carburized Extension Rod for Bench Drilling

Product Details:

Place of Origin: China
Brand Name: PRODRILL
Certification: ISO:9001
Model Number: Extension rod for drilling, T38, MM, 3660mm

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pcs
Price: $1~$300/pcs
Packaging Details: WOODEN BOX
Delivery Time: 10-15 DAYS
Payment Terms: T/T, L/C,western union etc.
Supply Ability: 5000Pcs/Month
Contact Now
Detailed Product Description

Extension drifter rod

Extension rod, other names are Extension drill steel, Extension drill rod, and Extension steel, M/F rod ( Speed rod ) , Produce Hexagonal and round cross sections, Hexagon rods are more rigid, heavier and transfer energy more efficiently, while increasing flushing. Round rods are generally lighter than hexagonal rods and are normally used in extension drilling applications. With the longer steel tending to be larger in diameter, conventional extension steel is characterized by a duplicate thread on each end of the steel.

Male/Male rod,Male/Female(M/F)Rod-Speed rod M/F drill steel is an alternative to couplings sleeves to include the female part of the threaded connection as an integral part of the drill steel. M/Fdrillsteelprovidesmorerigidconnectionsandiseasiertouncouple and handle. The service life also tends to be better than with separate couplings.

For Extension Rod and M/F steel process, the below two different types of heat treatment are used to strengthen high speed and powerful percussive drill string components to maximize their performance and reliability.-Cannibalization is a process used to harden the entire rod surface both internally and externally to strengthen and extend the life of the rod. - High Frequency Induction is a process where only the thread ends of the rod are hardened to lengthen thread life.



Drifter rod, another names are tunneling steels, tunneling rod, drifting drill rod, has Round and hexagon rod available, most of drifting drill steel with drill Steel Hexagon is for tunneling and drifting drilling application. Hexagon rods are more rigid, heavier and transfer energy more efficiently,while increasing flushing.

It is common practice to bump up the drive end of drifting steel for added strength at the rock drill end to accommodate larger diameter and shank adapters. Drill steel is available in many standard lengths to match the drill feeds on a multitude of available drifting jumbos.Two different types of heat treatment are used to strengthen our percussive drill string components to maximize their performance and reliability. Cannibalization and middle frequency induction surface quenching as two process for strength the total quality and performance and life.



Product Name:

Extension rod / Drift rod

Description:

Extension rod

Thread drill rod Made with best quality carbon steel bar,

through heat treatment like famous brands

Material:

carbon steel bar

MOQ:

5pcs

Body Type

Round shape and  hexagonal type

Thread type

R25,R28,R32,R38,T38,T45,T51

Diameter

Hex25,Hex28,Rd32,Rd38,Rd45,Rd51

Type

Thread Extension Rod and MF rod

Length

600mm-6400mm



Main Products:

1-12 inch middle-low/high air pressure DTH hammers & bits
Big hole high air pressure DTH hammer using in water well, oil, gas and construction drilling
Eccentric overburden drilling Equipment
Hole opener bit
Rock thread bit (R22, R25, R28, R32, R35, R38, T38, T45,T51, ST58,GT60)

Extension Rod, M/F Rod, M/m Rod, Drift Rod,
Shank adapter, coupling sleeves and all kinds of adapters

Advantages:

Compared with the oversea brands, our advantages are bellowing:

a. Our products can match over 95% against the original products

b. Price are competitive against the famous brands and best quality against the small factory

About Us:

1.    Our factory has been specialized in manufacturing drilling tools and spare parts for over 10 years.

2.    We have advanced technology and equipment.

3.    Our technician has more than 13 year’s professional working experience.

4.    Rock drilling tools are exported throughout the world. Main market: Norway, Turkey, USA, Canada, Australia, Brazil, Uruguay, Iran, Philippines, Thailand, India, etc.
